工作温度：一般型号不超过70℃，
型号后带105的*高不超过105℃
*低环境温度：固定敷设：-40℃ 非固定敷设：-15℃
额定电压U0/U: 300/500V
*小弯曲半径： 无铠装层电缆应不小于电缆外径的8倍
带铠装层的电缆不小于电缆外径的16倍
生产厂家：天津市双星特种线缆有限公司
联系人：杜经理13207689690（微信）
序号 No. 型号
Type 产品名称
Names of Product 备注
Remark
1 DJYPV 铜芯
聚乙烯绝缘
聚氯乙烯护套铜丝编织分屏蔽电子讦算机电缆
Computer cable with Cu conductor，PE insulation and PVC sheath, Cu-wire braided individual shield.
聚乙烯绝缘聚氯乙烯护套计算机缆有优良的电性能工作
电容小绝缘电阻高
PE insulated and PVC sheathed computer cables have excellent electrical characteristics, small working capacitance and high insulation resistance
2 DJYPVP 铜芯聚乙烯绝缘聚氯乙烯护套铜丝编织分屏蔽及总屏蔽电子讦算机电缆
Computer cable with Cu conductor，PE insulation and PVC sheath, Cu-wire braided individual and collective shield.
3 DJYVP 铜芯聚乙烯绝缘聚氯乙烯护套铜丝编织总屏蔽电子讦算机电缆
Computer cable with Cu conductor，PE insulation and PVC sheath, Cu-wire braided collective shield.
4 DJYP2V 铜芯聚乙烯绝缘聚氯乙烯护套铜/塑
复合膜分屏蔽电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Cu/plastic composite film individual shield.
5 DJYP2VP2 铜芯聚乙烯绝缘聚氯乙烯护套铜/塑复合膜分屏蔽及总屏蔽电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Cu/plastic composite film individual and collective shield.
6 DJYVP2 铜芯聚乙烯绝缘聚氯乙烯护套铜/塑复合膜总屏蔽电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Cu/plastic composite film collective shield.
7 DJYP3V 铜芯聚乙烯绝缘聚氯乙烯护套铝/塑复合膜分屏蔽电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Al/plastic composite film individual shield.
8 DJYP3VP3 铜芯聚乙烯绝缘聚氯乙烯护套铝/塑复合膜分屏蔽及总屏蔽电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Al/plastic composite film individual and collective shield.
9 DJYVP3 铜芯聚乙烯绝缘聚氯乙烯护套铝/塑复合膜总屏蔽电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Al/plastic composite film collective shield.
10 DJYPV22 铜芯聚乙烯绝缘聚氯乙烯护套铜丝编织分屏蔽
钢带铠装电子讦算机电缆
Computer cable with Cu conductor，PE insulation and PVC sheath, Cu-wire braided individual shield，and steel tape armoring.
11 DJYPVP22 铜芯聚乙烯绝缘聚氯乙烯护套铜丝编织分屏蔽及总屏蔽钢带铠装电子讦算机电缆
Computer cable with Cu conductor，PE insulation and PVC sheath, Cu-wire braided individual and collective shield，and steel tape armoring.
12 DJYVP22 铜芯聚乙烯绝缘聚氯乙烯护套铜丝编织总屏蔽钢带铠装电子讦算机电缆
Computer cable with Cu conductor，PE insulation and PVC sheath, Cu-wire braided collective shield，and steel tape armoring.
13 DJYP2V22 铜芯聚乙烯绝缘聚氯乙烯护套铜/塑复合膜分屏蔽钢带铠装电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Cu/plastic composite film individual shield，and steel tape armoring.
14 DJYP2VP2-22 铜芯聚乙烯绝缘聚氯乙烯护套铜/塑复合膜分屏蔽及总屏蔽钢带铠装电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Cu/plastic composite film individual and collective shield，and steel tape armoring.
15 DJYVP2-22 铜芯聚乙烯绝缘聚氯乙烯护套铜/塑复合膜总屏蔽钢带铠装电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Cu/plastic composite film collective shield，and steel tape armoring.
16 DJYP3V22 铜芯聚乙烯绝缘聚氯乙烯护套铝/塑复合膜分屏蔽钢带铠装电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Al/plastic composite film individual shield，and steel tape armoring.
17 DJYP3VP3-22 铜芯聚乙烯绝缘聚氯乙烯护套铝/塑复合膜分屏蔽及总屏蔽钢带铠装电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Al/plastic composite film individual and collective shield，and steel tape armoring.
18 DJYVP3-22 铜芯聚乙烯绝缘聚氯乙烯护套铝/塑复合膜总屏蔽钢带铠装电子计算机电缆
Computer cable with Cu conductor, PE insulation and PVC sheath, Al/plastic composite film collective shield，and steel tape armoring.
双星产品特点：
1.导体采用软结构时在型号后加“R”,采用7股胶合时在规格后面加“B”.
2.产品具有良好的抗电场、磁场干扰性能，并具有良好的防芯与芯之间的干扰性能。
3.在低频、高频、超高频及变频等场合下，仍具有精确地抗干扰性能。
4.阻燃型电缆、低烟无卤型电缆、耐火型电缆，需在电缆型号前加ZA、WDZ、NH即可。
天津市双星特种线缆有限公司，是为现代高科技和自动化配套的专业线缆生产企业。
我公司生产的“申易牌”线缆行销全国各地，在冶金、电子、石油、化工、汽车、建筑、电力、消防、通信等领域中得到广泛的应用，此外双星产品直接或间接为高科技产品配套出口，也获得了国外客商的称赞。
