特性
·该产品采用阻燃技术，实现了低毒、低烟、不熔融滴落和对环境不造成任何危害；
·该产品纤维及纺织品同时具有阻燃和抗熔滴的效果，其应用性能、安全性能和附加值大大提高，可以广泛应用于各领域；
·符合国家防火分类标准GB5455-85
Speciality:
Adopting the inflaming retarding technology. Low posion, low-smoke, infusible, fused drop resistance, no any harmfulness to the environment.
Conform to European and American classifications for nonflammability( e.g DIN53438-F1 , UL900-class 2 with flameout)
Used in the plank filter and foldaway filter
Paper frame, galvanization frame, aluminum frame are in available.
用途
适用于各种工业用途,如防治污染、公共建设、空调业、电子业,制药业,食品业等；
适用于粗尘过滤，中效空气过滤系统的预过滤。
Using:
Applied to the industry using, such as air-condition industry, electronic industry, pharmacy, food factory, etc.
Applied to the pre-filtration of the coarse efficiency filter system and medium efficiency filter system.
性能参数Specification
型号 Type F-160 F-200 F-300 F-400
材质 material POLYESTER
测试风速
Air velocity 2.0m/S 2.0m/S 1.5m/S 1 m/S
初始效率（％）
Initial efficiency ＜20 ＜20 ＜20 ＜20
初阻力
Initial efficiency 20 Pa 25 Pa 30Pa 35Pa
终阻力
Final efficiency 200Pa 250Pa 260Pa 280Pa
平均计重效率％
Avg.arrestance 85％ 85％ 88％ 91％
持续耐温
Temp.resistance 140℃ 140℃ 140℃ 140℃
瞬间耐温
Temp short peaks 160℃ 160℃ 160℃ 160℃
*大容尘量
Dust holding capacity 450 550 620 730
过滤级别
Filtration class G3 G3 G4 G4
厚度
thickness 10mm 15mm 15mm 20mm
标准尺寸（M）
Roll sizes standard 2.0*20 2.0*20 2.0*20 2.0*20
注：可按客户要求订做. Note:Other specifications are available on request.
