特点：
1、电阻
对焊机是将两工件端面始终压紧，利用电阻热将接触部分加热至塑性状态，然后迅速施加顶锻压力或不加顶锻压力只保持焊接压力，来完成焊接的方法。
2、与闪光对焊相比，电阻对焊操作简单，价格便宜，焊接效率高，焊接后
接头光滑，毛刺小。
3、结构设计精巧，对精细不一的工件焊接容易调整,*的对焊机控制电路，确保焊接质量。
4、主要用于对焊截面积小于250mm的金属型材，如铁线、板料、
管材等。
Main Principle:
1、AC Resistance Butt Welding is the welding method that the end surfaces of two parts are pressed tightly,and the resistance heat is used to heat up the surfaces to the plasticized status,then the upsetting force quickly press them together more tight again or without applying the upsetting force pressure,just only hold on the welding pressure to complete the welding.
2、Compared to Flash Butt Welding,Resistance Welding is much easily to for worker use and operate,the cost is much lower,welding productivity is also higher,The welded joint is smooth.and the welding burrs are small
3、The structure is designed compactly which is very easily to be adjusted to weld different parts. The special butt welding control circuits ensure the welding quality.
4、Mainly used for butt welding various metal material with welding section area less than 250mm,such as iron,wires,pipes,etc.
主要技术参数：
Main Technical Parameter:
参数
Parameter 额定容量
Rated Capacity 额定输入电压
Rated Input Voltage 额定频率
Rated Frequency *大短路电流
Max Short Current 负载持续率
Rated Duty Cycle *大夹紧力
Max Clamping Force *大顶锻力
Max Upsetting Force 冷却水流量Cooling Water Required 外形尺寸Over Dimensions L*W*H 平均重量
Average Weight
型号
Model No.
TUN1-25 25KVA 380V 50/60Hz 11000A 50％ 3900N 1500N 150L/H 90*80*120CM 300Kg
TUN1-35 35KVA 380V 50/60Hz 15000A 50％ 3900N 1500N 150L/H 90*80*120CM 350Kg
TUN1-50 50KVA 380V 50/60Hz 19000A 50％ 3900N 1500N 150L/H 90*80*120CM 400Kg
TUN1-75 75KVA 380V 50/60Hz 23500A 50％ 6100N 2500N 200L/H 90*80*120CM 450Kg
TUN1-100 100KVA 380V 50/60Hz 26000A 50％ 6100N 2500N 200L/H 90*80*120CM 500Kg
TUN1-150 150KVA 380V 50/60Hz 31000A 50％ 8000N 3900N 300L/H 135*80*160CM 550Kg
TUN1-200 200KVA 380V 50/60Hz 35000A 50％ 8000N 3900N 300L/H 135*80*160CM 650Kg
