特点及用途:
1.
电容放电焊接，时间短，焊点变形小，外表美观
2.采用单片机集成控制，功能齐全，性能可靠，且充电电压具有反馈控制，电压稳定性好，焊接质量高
3.输出与电网隔离，焊接规范不受网压波动影响，功率因数高,节能省电
4.配合不同电极，可用于焊接钢、铝、银、
不锈钢、镍等各类金属，线材、板材的精密焊接
Features and application:
1. Capacitor discharge welding, the time is short, the solder joint deformation is small, the appearance is beautiful
2. With single chip microcomputer integrated control, complete functions, reliable performance, and the charging voltage with feedback control, voltage stability, high welding quality
3. Output and grid isolation, Welding specification is not affected by power grid voltage fluctuation, Power factor is high, energy saving
4. With different electrodes, can be used for steel, aluminum, silver, stainless steel, nickel and other types of metal, wire, sheet metal precision welding
主要技术参数 Main Technical Parameters：
参数
Parameter
型号
Model No. 输入电压Input Voltage 焊接功率Welding Power 电容量Capacitance 储能量Energy Storage 焊接臂长
Welding
Arm Length 电极行程Electrode Stroke 电极压力
Electrode Pressure 总重量
Total Weight
TDR-2KVA 220V 2KVA 4500μF 500J 120MM 50MM 1000N 280KG
TDR-3KVA 220V 3KVA 13500μF 1500J 380MM 60MM 2500N 460KG
TDR-5KVA 380V 5 KVA 27000μF 3000J 380MM 60MM 3900N 700KG
TDR-7KVA 380V 7 KVA 47000μF 4500J 380MM 60MM 3900N 850KG
TDR-10KVA 380V 10 KVA 79000μF 8000J 380MM 60MM 6280N 1000KG
TDR-12KVA 380V 12 KVA 98000μF 10000J 380MM 60MM 6280N 1200KG
TDR-16KVA 380V 16KVA 120000μF 12000J 380MM 60MM 12000N 1500KG
TDR-20KVA 380V 20KVA 150000μF 15000J 380MM 60MM 15000N 1800KG
