本机型
包覆机传动使用台湾
变频器，刮胶结构采用滚刮结合。压轮使用硅胶，连接杆调制处理，红外线恒温加热，适用于木制品、铝塑型材、发泡材料等各种线条的表面包覆PVC、装饰
油漆纸。贴出的线条四边表面平整光滑牢固、不起泡、不变色。
型号 Model XRBL300-A
*大包覆宽度 Max. wrapping width 300mm
型材*大高度 Max. height of profiLED base material 80mm
*小加工型材长度 Min. processing length 600mm
异型材速度 Feeding speed of profiLED base material 0-23M/min
总功率 Total Power 4.5kw
外形尺寸 Figure dimension 3900*1000*2000mm
重量 Weight 1840kg
The machine is especially used in field of sticking PVC film and melamine paper onto decoration strips, aluminum and plastic material. Adopting high standard in gelatinizing, the machine could cover various angles, curve, concave & convexity, slot, wrap, border etc. which suit for construction material, furniture, table, window & door, decorative strip and relative factories. Complicated-shaped products’ surface could be turned into perfect impact.
XRBL300-C热胶包覆机 Multifunctional Lar (Hot Glue)
本机为专业的实木单板曲面包覆机，可将各种实木薄片、浸漆纸等材料完美的贴覆于
踢脚线、门窗套线、楼梯
扶手等各种线条的表面，一次性完成表面、侧面、底边的贴覆。底轮全部采用
硅橡胶铝轮，耐磨性好，不粘
热熔胶，使用寿命长。电气控制键选用国内知名品牌，故障率低。
型号 Model XRBL300-A
*大包覆宽度 Max. wrapping width 300mm
异型材速度 Feeding speed of profiLED base material 0-23M/min
总功率 Total Power 5.25kw
外形尺寸 Figure dimension 5500*900*2100mm
重量 Weight 1840kg
This machine is just used for wrapping the real wood. It can wrap various thin wood or melamine paper on kick board, set lines of door and windows, and railings of stairs. The wrapping of surface, sides and bottom are accomplished in a single process. The bottom wheels are all made by silicon rubber and aluminum. They are wearable and not sticky to the glue. So they can be used for a long time. The electronic controlling components use famous brand products in China and they seldom breaks down.
万能包覆机（热胶）
主要利用压轮对型材工件截面轮廓逐点包络贴压成型的基本原理，将各种
装饰膜贴覆于工件表面。配备冷热两套涂胶系统，具备冷热胶两种机型的功能，可实现PVC膜、
木皮u、木纹纸等装饰材料的贴膜。自动纠偏装置可以在不停机的状态下随时调整装饰膜的位置，大大降低了废品率。是用于实木、
密度板、铝合金、塑钢、木塑及其他材料的表面包覆。使产品档次大大提高。可根据客户需要，加装棍胶、乳胶系统、
修补机构、切断机构、
喷涂机构等装配装置。
