金属型
软管及
接头系列 METAL HOSE AND CONNECTOR SERIES
FC 加棉线平包耐压型软管 Plus cotton flat plastic pressureproof hose
颜色：黑色、灰色
温度范围： -30℃~+110℃
材质：内部镀锌
钢带，钢带内嵌棉线，外层PVC披覆
特性：●外层PVC，添加防火
阻燃剂，防老化
●内部钢带为单扣型，内嵌棉线防止脱扣，耐压性好
说明：其他规格可依要求定制
Color：Black and Gray
Temperature Range:-30℃~+110℃
Material：Internal galvanized steel strip, strip embedded thread, the outer PVC coating Property：
●Surface PVC, adding fire retardant, anti aging
●Internal steel by squarelocked, with cotton to preventsteel trip，good pressure resistance performance
Note: Other specifications can be customized
型号 公制 英制 内径 外径 弯曲半径 包装规格
FCB008 FCG008 Φ8 1/4 7.7-8.0 11.8-12.1 50 100
FCB010 FCG010 Φ10 5/16 9.7-10.0 12.8-14.5 55 100
FCB012 FCG012 Φ12 3/8 12.3-12.8 16.6-17.5 60 50
FCB015 FCG015 Φ15 1/2 15.8-16.3 20.6-21.2 80 50
FCB020 FCG020 Φ20 3/4 20.8-21.3 24.6-25.5 100 50
FCB025 FCG025 Φ25 1 26.4-27.1 30.8-31.7 120 50
FCB032 FCG032 Φ32 1-1/4 35.1-35.8 38.7-39.6 150 25
FCB038 FCG038 Φ38 1-1/2 40.1-40.6 45.7-46.6 180 25
FCB051 FCG051 Φ51 2 51.3-51.9 58.6-59.5 220 20
FCB064 FCG064 Φ64 2-1/2 63.0-63.6 71.0-73.0 310 10
FCB075 FCG075 Φ75 3 78.6-79.6 87.0-89.0 350 10
FCB100 FCG100 Φ100 4 100.8-101.3 112.3-114.3 410 10
